- Frameset
-
- ABRAZ. SILLÍN
- Alloy, 38.6mm
-
- CUADRO
- FACT 11m carbon chassis and rear-end, S-Sizing Enduro Race Geometry, SWAT™ Door integration, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 170mm of travel
- Suspension
-
- AMORTIGUADOR
- FOX FLOAT X2 Factory, Rx Trail Tune, 2-position adjustment, high and low speed rebound and compression adjust, Trunnion mount, 205x60mm
-
- HORQUILLA
- FOX FLOAT 38 Factory, GRIP2 damper, Kashima Coating, 15x110mm, 44mm offset, 170mm of travel
- Cockpit
-
- MANILLAR
- Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm, 35.0mm
-
- TIJA DE SILLÍN
- RockShox Reverb AXS, 30.9, 1X remote, (S2/S3: 150mm, S4/S5:170mm)
-
- PUÑOS
- Deity, Knuckleduster, Black
-
- POTENCIA
- Deity, 35.0mm
-
- SILLÍN
- Bridge, 155/143mm, Hollow Ti-rails
- Brakes
-
- Frenos DELANTERO
- SRAM Code RSC, 4-piston caliper, hydraulic disc, 220mm
-
- Frenos TRASERO
- SRAM Code RSC, 4-piston caliper, hydraulic disc, 200mm
- Drivetrain
-
- PLATOS
- 48/35T
-
- CASETE
- Sram XG-1299, 12-Speed, 10-52t
-
- CAMBIO
- SRAM XX1 Eagle AXS
-
- CADENA
- SRAM XX1 Eagle
-
- PEDALIER
- SRAM X01 Eagle, DUB, 170mm
-
- MANDOS DE CAMBIO
- SRAM Eagle AXS Rocker Paddle
-
- CAJA PEDALIER
- SRAM DUB, BSA 73mm, threaded
- Wheels
-
- BUJE DELANTERO
- Roval Traverse SL, sealed cartridge bearings, 15mm thru-axle, 110mm spacing
-
- BUJE TRASERO
- Roval Traverse SL, DT Swiss Star Ratchet, 54t engagement, SRAM XD driver body, 12mm thru-axle, 148mm spacing
-
- LLANTAS
- Roval Traverse SL 29, hookless carbon, 30mm inner width, 2Bliss Ready, hand-built, 28h
-
- NEUMÁTICO TRASERO
- Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 29×2.3″
-
- RADIOS
- DT Competition Race
-
- NEUMÁTICO DEL.
- Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29×2.3″
-
- CÁMARAS
- Standard, Presta valve
-
Talla | S2 | S3 | S4 | S5 |
---|---|---|---|---|
Crank Length | 170 | 170 | 170 | 170 |
Handlebar Width | 800 | 800 | 800 | 800 |
Stem Length | 35 | 50 | 50 | 50 |
Saddle Width | 155 | 143 | 143 | 143 |
Seatpost Length | 150 | 150 | 170 | 170 |
B-B Drop | 21 | 21 | 21 | 21 |
B-B Drop (low BB) | 28 | 28 | 28 | 28 |
B-B Height | 354 | 354 | 354 | 354 |
B-B Height (low BB) | 347 | 347 | 347 | 347 |
Chain-Stay Length | 442 | 442 | 442 | 442 |
Fork Length (full) | 581 | 581 | 581 | 581 |
Fork Rake/Offset | 46 | 46 | 46 | 46 |
Front-Center (low BB) | 777 | 806 | 833 | 862 |
Head-Tube Angle | 64.3 | 64.3 | 64.3 | 64.3 |
Head-Tube Angle (low BB) | 63.9 | 63.9 | 63.9 | 63.9 |
Head-Tube Length | 95 | 100 | 110 | 120 |
Reach (low BB) | 437 | 464 | 487 | 511 |
Seat-Tube Angle | 76 | 76 | 76 | 76 |
Seat-Tube Length | 400 | 420 | 440 | 465 |
Stack (low BB) | 616 | 620 | 629 | 638 |
Top Tube Length (Horizontal) | 591 | 619 | 644 | 670 |
Trail (low BB) | 132 | 132 | 132 | 132 |
Wheelbase | 1217 | 1246 | 1274 | 1302 |
